1197 AMADA C Frame Single Crank Press

Price 800000 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

1197 AMADA C Frame Single Crank Press Specification

Material
Mild Steel

Power
80 Ton

Voltage
415 V

Dimension (L*W*H)
2100 mm x 1100 mm x 2700 mm

Product Type
C Frame Single Crank Press

Application
Punching, Stamping, Forming

Accessories
Die Set, Foot Switch, Control Panel

1197 AMADA C Frame Single Crank Press Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
100 Units Per Month

Main Domestic Market
All India

About 1197 AMADA C Frame Single Crank Press

C FRAME SINGLE CRANK PRESS

AMADA JAPAN
MODEL: TP-60
SKU # 1197

Brief Specifications/ Details

Cap: 60Tons
Stroke: 100mm
Bed Size: 810 x 530mm
RAM Size: 400 x 300mm
Die Height: 260mm
Adjustment: 60mm
SPM: 50

Superior Build for Reliable Performance

The 1197 AMADA Single Crank Press showcases a durable C Frame structure crafted from mild steel, ensuring stability and longevity even during demanding stamping operations. Its high shut height and slide adjustment options provide adaptability for various tooling configurations, making it ideal for manufacturers seeking consistent accuracy in metalworking processes.

Optimized for Versatile Metal Forming

Engineered for flexibility, this press is suitable for a range of applications including punching, stamping, and forming. The ample table size and adjustable slide enhance usability, accommodating diverse workpiece dimensions and complex shapes. Integrated accessories, such as the die set and foot switch, contribute to higher productivity and ease of use.

FAQs of 1197 AMADA C Frame Single Crank Press:

Q: How is the 1197 AMADA C Frame Single Crank Press operated?

A: The press is operated via an electric control system, which allows for precise adjustment of operational parameters. It also includes a foot switch and a control panel, making hands-free and safe operation possible during high-volume production.

Q: What are the main applications for this press?

A: The 1197 AMADA C Frame Single Crank Press is primarily used for punching, stamping, and forming mild steel materials. It is suitable for manufacturing environments where accurate and repeatable metalworking processes are essential.

Q: When should the slide adjustment be used?

A: The slide adjustment, offering a range of 75 mm, should be used when altering die positions or adapting the press for different thicknesses and shapes of workpieces. This flexibility ensures consistent accuracy for varying production requirements.

Q: Where is the 1197 AMADA Press commonly installed?

A: This press is commonly installed in industrial facilities, manufacturing plants, and workshops in India that require reliable and powerful metal forming equipment for continuous production tasks.

Q: What is the process for installing accessories such as the die set and foot switch?

A: Installation involves securely mounting the die set onto the press table and properly connecting the foot switch to the control panel. The process should be performed according to the manufacturers instructions to ensure operational safety and efficiency.

Q: How does the C Frame structure benefit the operation?

A: The C Frame design offers unobstructed access to the workpiece and tooling, improving ease of setup and material handling. Its rigidity supports consistent force distribution, which is crucial for maintaining accuracy during stamping and forming operations.

Q: What advantages does the maximum stroke per minute bring to production?

A: A max stroke rate of 45 spm enables efficient high-speed operation, enhancing throughput while maintaining precise control over forming and punching processes. This translates to reduced cycle times and increased productivity for manufacturers.
