1439 MINCHANG H FRAME DOUBLE CRANK

Price 8500000 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

1439 MINCHANG H FRAME DOUBLE CRANK Specification

Material
High Quality Steel

Power
110-3150 Ton

Voltage
380V / 415V, 3 Phase, 50/60 Hz

Dimension (L*W*H)
Customized as per specification

Application
Sheet Metal Forming, Automobile Parts Manufacturing, Electrical Components Production, Industrial Press Applications

Accessories
Automatic Lubrication System, Pneumatic Die Cushion, Light Curtain, Die Arm

Automation Grade
Automatic

Frame Type
H Frame (Double Crank)

Control System
PLC Controlled

Max Strokes Per Min
20-50 spm

Motor Power
15-110 kW

Slide Area
600 x 400 mm up to 2200 x 1100 mm (Depending on Model)

Stroke Length
150-500 mm

Bed Area
1100 x 700 mm up to 3000 x 1400 mm

Ram Adjustment
80 mm - 140 mm

Safety Features
Emergency Stop, Overload Protector, Interlock Guard

1439 MINCHANG H FRAME DOUBLE CRANK Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
100 Units Per Month

Main Domestic Market
All India

1439 MINCHANG H FRAME DOUBLE CRANK About

MINCHANG TAIWAN MODEL DA350D

H FRAME DOUBLE CRANK PRESS

MINCHANG TAIWAN

MODEL DA350D

SKU 1439

Brief Specifications Details

Cap 350Tons

Stroke 300mm

Bed Size 2500 x 1200mm

RAM Size 2320 x 1220mm

Die Height 700mm

Adjustment 200mm

SPM 24

Precision Engineering for Industrial Applications

The H Frame Double Crank from MINCHANG delivers superior accuracy and stability, thanks to its double crank design and solid H-frame structure. Ideal for industries demanding high tonnage and consistent output, it excels in sheet metal stamping and automotive component manufacturing.

Flexible Specifications to Fit Production Needs

With stroke lengths from 150 to 500 mm, ram adjustment capability, and customizable bed and slide areas, the machine accommodates various die dimensions and workpiece sizes. Power, voltage, and control settings are tailored to meet specific operational requirements.

Smart Automation and Safety Features

Automated with a PLC control system, the double crank press integrates leading safety mechanisms such as emergency stops, overload protectors, and interlock guards. These ensure both operator protection and prolonged equipment longevity in busy industrial settings.

FAQs of 1439 MINCHANG H FRAME DOUBLE CRANK:

Q: How does the double crank mechanism benefit sheet metal forming processes?

A: The double crank mechanism of the 1439 MINCHANG H Frame distributes force uniformly across the slide, enhancing precision and reducing deformation during sheet metal forming. This design ensures consistent quality and minimizes structural stress on workpieces.

Q: What types of industrial applications is this press suitable for?

A: This press is ideal for sheet metal forming, automobile parts manufacturing, electrical components production, and general industrial press operations, making it versatile for a range of high-demand manufacturing environments.

Q: When should I adjust the ram setting on this machine?

A: Ram adjustment is necessary when changing dies or workpiece thicknesses. With an 80 mm to 140 mm adjustment range, operators can optimize the press for varying production requirements and improve forming accuracy.

Q: Where can the MINCHANG H Frame Double Crank be installed?

A: Thanks to its customizable dimensions and power options, this press can be installed in manufacturing plants, automotive workshops, and electrical component production facilities, particularly those with 3-phase, 380V/415V, 50/60 Hz power supply.

Q: What safety features are integrated into this press?

A: Key safety features include an emergency stop button, overload protector, interlock guard, and light curtain, all of which help prevent accidents and safeguard operators during operation.

Q: How does the PLC control system improve operation efficiency?

A: The PLC control system automates repetitive tasks, monitors press performance, and enables quick recipe changes, significantly improving productivity, production consistency, and minimizing downtime.
