Send Inquiry1343 CHINFONG C Frame Single Crank Press
Price 500000 INR/ Unit
MOQ : 1 Unit
1343 CHINFONG C Frame Single Crank Press Specification
- Material
- Mild Steel
- Power
- 15 Ton
- Voltage
- 380 V
- Product Type
- C Frame Single Crank Press
- Dimension (L*W*H)
- 1000 x 700 x 2100 mm
- Application
- Sheet Metal Forming, Punching, Stamping, Embossing
- Accessories
- Electrical Panel, Foot Switch, Safety Guard
- Bolster Size
- 650 x 400 mm
- Weight
- Approx. 1800 kg
- Main Drive
- Single Crank
- Shut Height
- 220 mm
- Model
- 1343
- Ram Size
- 320 x 220 mm
- Motor Power
- 3 HP
- Control System
- PLC Control
- Stroke Length
- 90 mm
- Number of Strokes per Minute
- 50 SPM
- Frame Type
- C Frame
- Slide Adjustment
- 60 mm
1343 CHINFONG C Frame Single Crank Press Trade Information
- Minimum Order Quantity
- 1 Unit
- Payment Terms
- Cash in Advance (CID)
- Supply Ability
- 100 Units Per Month
- Main Domestic Market
- All India
1343 CHINFONG C Frame Single Crank Press About
C FRAME SINGLE CRANK PRESS
CHIN FONG TAIWAN
MODEL: OCP-35N
SKU # 1343
Brief Specifications/ Details
- Cap: 35 Tons
- Stroke: 70mm
- Bed Size: 800x 400mm
- Ram Size: 360 x 250mm
- Die Height:220mm
- Adjustment: 55mm
- SPM: 55
Reliable Performance and Versatility
The 1343 CHINFONG C Frame Press delivers consistent output, making it ideal for manufacturers working with sheet metal. Its single crank drive ensures uniform force distribution, which is crucial for precise punching, stamping, and forming tasks. The sturdy C Frame design adds to the machines stability and longevity.
Advanced Control and Safety Features
Equipped with PLC controls and integrated safety components such as a foot switch and safety guard, this press guarantees both operational efficiency and user protection. The electrical panel supports easy monitoring and maintenance, streamlining the workflow for operators.
Optimized for Industrial Applications
With a 15-ton capacity, this machine is suited to demanding sheet metal processes in manufacturing environments across India. Its mild steel construction, compact dimensions, and 1800 kg weight allow for integration into various production lines while guaranteeing durability.
FAQs of 1343 CHINFONG C Frame Single Crank Press:
Q: How does the 1343 CHINFONG C Frame Press benefit sheet metal forming operations?
A: This press provides precise and consistent force, which is essential for high-quality sheet metal forming, punching, stamping, and embossing. Its robust build and reliable single crank mechanism ensure long-term performance and minimal maintenance.Q: What materials and applications is the 1343 model suitable for?
A: The 1343 C Frame Single Crank Press is especially designed for mild steel sheet metal processing, including forming, punching, stamping, and embossing tasks in industrial manufacturing.Q: When should the slide adjustment or shut height be modified?
A: Slide adjustment and shut height should be modified when changing die sets or working with workpieces of different thicknesses. This ensures proper alignment and optimal operation for each specific application.Q: Where can this machine be integrated in a manufacturing setup?
A: Owing to its manageable size and weight, the press can be installed on most factory floors, ideally near sheet metal feeding stations. Its power and reliability make it suitable for various sheet metal production lines in India.Q: What is the typical process for operating this press machine?
A: Operators first secure the required die and adjust settings such as stroke length and shut height. The machine is then activated using the PLC control and foot switch, ensuring efficient and safe operation for each punching or forming cycle.Q: What is the main advantage of the PLC control system in this press?
A: The PLC control system allows for precise and programmable operations, enhancing process repeatability and safety while simplifying troubleshooting and adjustments during production.
