1373 AIDA C Frame Single Crank Press

Price 700000 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

1373 AIDA C Frame Single Crank Press Specification

Material
Mild Steel

Power
110 Ton

Voltage
415 V

Product Type
C Frame Single Crank Press

Dimension (L*W*H)
2130 x 1295 x 2800 mm

Application
Sheet Metal Forming, Punching, Blanking

Accessories
Standard Accessories

Stroke Length
120 mm

Ram Adjustment
80 mm

Model Name
1373 AIDA

Shut Height
360 mm

Bolster Thickness
110 mm

Motor Power
7.5 kW

Bed Size
1000 x 550 mm

Max Stroke Per Minute
45 SPM

1373 AIDA C Frame Single Crank Press Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
100 Units Per Month

Main Domestic Market
All India

About 1373 AIDA C Frame Single Crank Press

C FRAME SINGLE CRANK PRESS

AIDA JAPAN

MODEL: PC-5(II)
SKU # 1373

Brief Specifications/ Details
Cap: 55Tons

Stroke: 150mm

Bed Size: 850x500mm

Ram Size: 480x360mm

Die Height: 300mm

Adjustment: 55mm

SPM: 60

Precision and Power for Metal Forming

The AIDA C Frame Single Crank Press offers outstanding power and precision for sheet metal forming, punching, and blanking. With a 110-ton capacity and 45 strokes per minute, it maintains optimal speed and efficiency, while its generous bed size enables handling of various workpiece dimensions.

Enhanced Adjustability and Durability

Featuring a ram adjustment of 80 mm and a solid bolster thickness, this press accommodates varying material thicknesses and forming needs. The mild steel construction ensures longevity and low maintenance, which is vital for rigorous manufacturing environments.

Reliable Performance and Safety

Built for reliability, the AIDA press integrates standard accessories and operates on a safe 415 V supply. Its design facilitates safe usage and easy integration within Indian manufacturing setups, supporting continuous operations and improved throughput.

FAQs of 1373 AIDA C Frame Single Crank Press:

Q: How is the 1373 AIDA C Frame Single Crank Press used for sheet metal forming applications?

A: The 1373 AIDA press is used for sheet metal forming, punching, and blanking by applying powerful, controlled force to shape or cut metal sheets. Its adjustable stroke length and ram allow precise customization for different material types and thicknesses.

Q: What are the key benefits of using this press in an industrial setting?

A: Key benefits include high tonnage (110 tons) for heavy-duty tasks, fast operation at up to 45 strokes per minute, and versatility with a spacious bed, adjustable ram, and reliable motor, making it efficient and cost-effective for large-scale manufacturing.

Q: When should manufacturers choose this press over other models?

A: Manufacturers should consider the 1373 AIDA press when they require robust pressing power, a large work area, high stroke speed, and reliable adaptation to various sheet metal thicknesses, particularly for continuous, large-batch production.

Q: Where is the 1373 AIDA C Frame Single Crank Press typically installed and operated?

A: This press is primarily installed and operated in industrial factories or workshops across India, particularly where high-volume sheet metal stamping, punching, and blanking processes are central to manufacturing operations.

Q: What is the process for adjusting the ram and shut height for different job requirements?

A: Operators can adjust the ram by up to 80 mm and set the shut height to 360 mm to accommodate specific die and material needs. These adjustments are done using accessible controls, allowing flexibility for varied production runs.

Q: How does its construction and accessories contribute to long-term durability?

A: Its solid mild steel frame ensures strength and resistance to wear, while standard accessories provide support for efficient tooling changes and operation, contributing to the presss long-term durability in demanding environments.

Q: What electrical and safety standards are met by the AIDA press?

A: The press runs on a stable 415 V voltage, commonly used in Indian industries, and incorporates safety features aligned with standard manufacturing practices, ensuring secure operation during continuous and high-pressure tasks.
